Tag: IS200SRTDH2ACB

The IS200SRTDH2A is a printed circuit board or PCB created by General Electric or GE as part of the Mark VI series. The Mark VI is the latest version of the General Electric Mark series. The Mark VI and other series in the Mark series are designed to manage and automate processes in gas turbine and steam turbine systems. These applications are used in many different industries around the world. The larger Mark VI turbine control system family offered by this IS200SRTDH2A DIN Rail RTD terminal board printed circuit board product must be described as such a huge functional improvement over the previous industry standard of the same name; Mark V Turbine control system series. The Mark VI series builds on the gas and steam applications achieved through the Mark V Series, adding possible functional applications for wind turbines based on alternative energy sources.

Hardware tips and specifications

The IS200SRTDH2A is a relatively small printed circuit board with varying electronic component sizes. Two (2) large terminals are located on the bottom edge of the IS200SRTDH2A, one above the other. Each terminal contains eighteen (18) terminals for a total of thirty-six (3) terminals. These silver metal terminals contained within the terminal are numbered one (1) to thirty-six (36) and bear white lettering. One (1) large connector port is connected to the upper boundary of the IS200SRTDH2A. This connector port is used to connect additional components or other boards to the IS200SRTDH2A. At the heart of the IS200SRTDH2A is an array of diodes and capacitors. The diode is shaped like a black rectangle. There are 24 diodes, divided into two (2) horizontal rows of twelve (12) diodes per row. Next to each diode are one (1) or two (2) rectangular small capacitors. The full part name of the device, IS200SRTDH2A, is printed in the upper left corner of the IS200SRTDH2A. The GE symbol is printed on the board below this part number.

Considering its position as a good primary source of DIN Rail RTD terminal board hardware components and component specification information IS200SRTDH2A, the part number of the IS200SRTDH2A DIN-RAIL RTD terminal board equipment is actually particularly relevant in these cases, Because its Mark VI turbine control system family is completely lacking in online information instruction manual documentation, it can be used for research purposes on this IS200SRTDH2A DIN Rail RTD terminal board personalized product page. As with any GE mark serial number, the IS200SRTDH2A DIN Rail RTD Terminal Module Function product number encodes a particular family of board-specific hardware details through a continuous set of function naming blocks of its characteristics. One of these blocks is the initial IS200 Series label itself, which is responsible for highlighting the normal Mark VI Series assembly version of the IS200SRTDH2A DIN Rail RTD terminal board product and its original GE manufacturing location in the country. Some other important qualities of IS200SRTDH2A DIN Rail RTD terminal board devices revealed in this way include:

SRTD Functional Product acronym
Conformal PCB coating style
Group 2 Mark VI series grouping
Class A Functional Product revision
