Material:High-grade copper alloy
Dimensions:170mm x 150mm x 20mm
Weight:0.75kg
Operating Temperature Range:-20°C to +85°C
Power Supply Voltage:DC 5V, 12V, 24V
Data Transmission Protocol:RS-485, CAN
Memory Capacity:32MB Flash, 16MB SDRAM
Processing Speed:800MHz ARM Cortex-A9
This precision circuit board is engineered for demanding applications requiring optimal signal integrity and minimal noise. The use of FR-4 material ensures stability and durability under varying environmental conditions.
The surface mount technology (SMT) assembly method guarantees high-quality production and reliable electrical connections, ensuring long-term performance without degradation.
Featuring a single-layer design, this PCB offers a balance between cost-effectiveness and functionality, making it suitable for a wide range of electronics projects.
With a current capacity of 10A at 5VDC and a maximum voltage of 12VDC, this module is capable of handling a broad spectrum of power requirements, from small circuits to moderate-sized systems.
Equipped with JST XH-2.0mm connectors, this PCB supports easy integration with other components, simplifying the assembly process and reducing the risk of connection errors.
